Wire Pointing Welding Machine
These machines area unit used for the sharpening of nibs of the wires that have low and high carbon content further as copper wires. We manufacture high normal Wire inform Machine, of inflexible quality and high practicality. This machine could be a quite wire head roller and is appropriate rolling soft wire. The operation of this machine is incredibly straight forward and convenient. These machine are suitable for pointing different types of material like mild steel, high carbon steel, aluminum and copper wires. It can be operate very easily. It is high durability. Our offered Wire Pointing Machine is preferred over other machines for its accuracy, superior performance and low power consumption
Applications
Applications of the Wire Pointing Machine include:
Sharpening Nibs of Wires
Rolling Wires
Technical Data
POINTING MACHINE FOR 1.5mm to 8mm Diameter | |||||
Sr. No | Specifications | ||||
1 | Machine Capacity | 1.5 mm To 8 mm Wire Dia. | 2 mm To 16 mm Wire Dia. | ||
2 | Roller Dia | 85mm | 95mm | ||
3 | No of Rollers | 2 Nos. | 2 Nos. | ||
4 | Roller Material | Made Out Of HO/ HC Material Hardened Ground | Made out of HC/HC Material Hardened Ground | ||
5 | Main Body | Fabricated Out Of M.S. Channel, Angle, Plates | Fabricated Out Of M.S. Channel, Angle, Plates | ||
6 | Machine RPM | 45 RPM | 45 RPM | ||
7 | Motor | 5 HP, 1440 RPM | 7.5 HP, 1440 RPM | ||
8 | Drive | Gear Drive | Gear Drive | ||
9 | Pressure Adjustment | Screw System with Handle | Screw System with Handle | ||
10 | Power Supply Required | 5 HP, 3 Phase 440V | 7.5 HP, 3 Phase, 440V |
Dimensions
Length: 650mm
Width: 430mm
Height: 1100mm
Weight: 100 to 120 kg
